Spouts /


            Fixed, cast spout                  Swivelling swan neck spout          Tubular spout
            Deck-mounted                       Deck-mounted                        Deck-mounted







                                                                                                                          BASINS




            • Spout L. 140mm, H. 120mm, M½".   • Swan neck spout M½".              • Tubular spout on base M½".
            • Reinforced fixing by 3 stainless steel screws.  • Fixing by back-nut.  • Chrome-plated brass.
            • Chrome-plated brass.             • Chrome-plated brass.              • Spout with smooth interior
            • Scale-resistant flow straightener regulated    • Scale-resistant flow straightener regulated    (reduces bacterial development).
             at 3 lpm.                           at 3 lpm.                         • Scale-resistant flow straightener.
            • 30-year warranty.                • 30-year warranty.                 • 30-year warranty.


                                                                                                 150
                                                                                              170
                        120                                120
                                                                                                        1/2"
                                                              150
                            1/2"                                1/2"                                15 max
                           140    30 max                             30 max
                                                                                                 204001
                          981142                              967152
                                                                                   Swivelling tubular spout Ø 22mm
                                                                                   L. 150mm H. 140mm, 3 lpm  1306T1
                                                Swivelling swan neck spout         L. 200mm H. 260mm, 3 lpm  1306T2
                                                L. 150mm H. 120mm        967152    L. 300mm H. 260mm         1306T3
            Fixed, cast spout         981142    L. 200mm H. 200mm        967202    Fixed tubular spout Ø 16mm  204001


            Fixed spout                        Fixed spout                         Fixed L-shaped spout
            Wall-mounted / Cross wall          For thin panels                     Wall-mounted












            • Spout Ø 32mm, M½".               • Spout L. 75mm, M½".               • Tubular spout Ø 18mm, M½".
            • Chrome-plated brass.             • For thin panels.                  • L. 120mm.
            • Scale-resistant flow straightener regulated    • Threaded rod can be cut to size.  • Chrome-plated brass.
             at 3 lpm.                         • Streamlined, ligature-resistant design.  • Flow straightener.
            • 30-year warranty.                • Chrome-plated brass.              • 30-year warranty.
                                               • Star-shaped scale-resistant flow straightener.
                       Ø 32  Ø 60  Ø 21  1/2"  • 30-year warranty.


                       120   165 max
                                                             Ø 48  Ø 21  1/2"                     10 max  1/2"
                          947151                                                              60
                                                            75  30 max                            120
            Cross wall spout with wall plate
            L. 120mm                  947151                  942040                             941922
            L. 170mm                  947157
            Wall-mounted spout no wall plate (recessed inlet)
            L. 110mm                  947120    Cross wall fixed spout              Wall-mounted L-shaped universal spout
            L. 160mm                  947170    For panels ≤ 30mm        942040    Star-shaped flow straightener  941120
            Wall-mounted spout with wall plate (recessed inlet)  Back-nut with 3 screws  826315  Flow straightener regulated at 3 lpm
            L. 120mm                  947135    Alternative cross wall lengths available on request  for panels ≤ 10mm  941922
