Additional fittings /

PREMIX NANO PREMIX COMPACT Pre-mixer Compact
Thermostatic mixing valve Thermostatic mixing valve

NEW

BASINS

• Thermostatic mixing valve for MW distribution. • Thermostatic mixing valve for MW distribution. • For installation beneath the basin.
• Temperature can be adjusted from 34 - 60°C. • Temperature can be adjusted from 30 - 60°C. • Nickel-plated body MF½".
• To be placed upstream of the tap. • To be placed upstream of the taps. • Controllable non-return valves and filters.
• Anti-scalding failsafe. • Anti-scalding safety. • 30-year warranty.
• Filters and non-return valves. • Filters and non-return valves.
• Thermal shocks are possible. • Thermal shocks are possible.
• Supplies 1 - 2 taps. • For 2 to 6 points-of-use.
• 30-year warranty. 75 • 30-year warranty.
120
3/8"
1/2" 1/2"
70
65
1/2" 1/2"
3/8" 34 3/8"
40
732012 1/2" 35 1/2"
733015
PREMIX NANO
Nickel, FFM ⅜" 732012 PREMIX COMPACT 200000
Polished, FFM ⅜" 732016 M½" 733015
Nickel, M½" Ø 15mm 732115 M¾" 733020
Nickel, F½" Ø 15mm 732115MEC M½" Ø 15mm 733115
Polished, M½" Ø 15mm 732116 M¾" Ø 15mm 733116 Pre-mixer Compact 200000

Reinforced exposed union ON/OFF waste HYGIÉNA waste
For TEMPOMATIC 3 and 4 With stainless steel valve With concave grid
NEW

• Reinforced exposed union. • Washbasin waste M1¼" • Hygienic washbasin waste, M1¼".
• Supplied with sleek concealment plate. with stainless steel valve with free flow. • Concave grid (no water retention).
• Recommended for the installation of • Recommended for all washbasins equipped • Free flow, with no central screw (avoids scale
TEMPOMATIC 3 or TEMPOMATIC 4 with electronic or time flow mixers/taps deposits and reduces bacterial development).
wall-mounted basin taps with exposed supply. and washbasins with an overflow. • Polished chrome-plated brass grid,
• 30-year warranty. • Open/close by pressing the top of the waste. chrome-plated ABS body.
• 30-year warranty. • Pre-scored waste: snap off sections can be
removed for models with overflow.
• Can be tightened to a minimum of 1mm
or maximum of 45mm.
• 30-year warranty.

Ø 63
47
Ø52 Ø 61
1/2" 1 - 45 Ø 39
Ø 42 30
35
Ø14
20 50 50
1"1/4 1"1/4
841215
581000 611
Reinforced exposed union 841215
with cover ON/OFF waste 581000 HYGIÉNA waste 611

Basins 69
