P. 68

/ Fittings for water fountains and hand washbasins


              Swan neck tap                                        Bubbler
              For water fountains                                  For water fountains













              • Instant shut-off.                                  • Instant shut-off.
              • Adjustable flow rate.                               • Adjustable flow rate.
              • Chrome-plated brass body and stainless steel spout.  • Chrome-plated brass.
              • 30-year warranty.                                  • M⅜".
                                                                   • 30-year warranty.
                                     90

                                  250


                                                                                         35
                                                                                               Ø 3
                                                                                         25 max
                                           Ø 3
                                  25 max   3/8"  19                                      3/8"  19

                                     311QU1                                               312QU1

              Swan neck tap
              For Rilsan tube 4   6                      311TR1
              M⅜"                                        311QU1    Bubbler                                    312QU1


              Push-button control                                  TEMPOSTOP
              For swan neck taps and bubblers                      For hand washbasins












              • Instant shut-off.                                  • Time flow ~7 seconds.
              • For swan neck spouts and bubblers.                 • Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 - 6 lpm.
              • Chrome-plated brass.                               • Rough cast brass body.
              • Connector for Rilsan tube 4   6.                   • Inlet M½".
              • 30-year warranty.                                  • To be placed behind hand washbasin wall plate.
                                                                   • 30-year warranty.


                                      Ø 40
                                                                                           4 min
                                                                                                1/2"
                                  Ø 33
                                            22 max                                      1/2"      28
                                       20                                                50  27  20


                                     319T61                                               748626
                                                                   TEMPOSTOP tap
                                                                   With push-button                           748626
                                                                   Without push-button                        748126
              Push-button control                        319T61    We recommend installing a TMV (see page 143)
