Time flow basin controls TEMPOSTOP /

• Water savings: 85%
• Vandal-resistant: solid brass, anti-blocking (AB) system

TEMPOSTOP TEMPOSTOP
Wall-mounted time flow basin tap Wall-mounted or cross wall time flow basin tap
BASINS

200 1/2"

50

746410
Wall-mounted lever-operated time flow tap

Ø50

• Time flow ~7 seconds. 1/2"
• Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 - 6 lpm. 150
• Tamperproof scale-resistant flow straightener.
• Chrome-plated solid brass body M⅜" or M½". 150 35
• Available with AB anti-blocking system: water only flows
when push-button is released.
• Push-button or lever-operated control. 748150
• 30-year warranty.
Wall-mounted time flow tap with swivelling spout:
• Time flow ~15 seconds. Suitable for wash tubs.

Ø 60
NEW
1/2" 1/2"
4 200 max Ø 21 1/2"
50 50
Ø 50 60
746000 746292
120 min 1/2"
Ø 21 1/2"
75 230 max
46
Ø 60 Ø 55
1/2" 50
2
1/2"
40
Ø 21 20 Ø 14 Ø 26 1/2" 748110
Cross wall time flow tap:
292015.2P 841315 822516
• Control ≤ 200mm and spout ≤ 230mm, cut-to-size.
• Anti-rotating pin and back-nut. AB anti-blocking system.
• Chrome-plated metal control.
TEMPOSTOP wall-mounted tap
M⅜" 744000
M½" (DZR brass) 746000
M½" with wall plate 746292
M½" and AB system 746001
TEMPOSTOP tap
Accessories Wall-mounted lever-operated tap 746410
Wall plates for taps Ø 60mm (2 per pack) 292015.2P Wall-mounted with swivelling spout 748150
Backplate elbow MF½" 841315
Cross wall and AB system 748110
Extension MF½" L. 50mm Ø 26mm 822516 Back-nut F½" with 3 stainless steel screws 826315
Extension MF½" L. 100mm Ø 24mm 822115
We recommend installing a TMV (see page 143)
We recommend installing a TMV (see page 143) Alternative cross wall lengths (up to 400mm) available on request

Basins 63
