/ Urinal controls TEMPOMATIC / TEMPOSTOP

• Water savings: 60%
• Vandal-resistant: cross wall installation, concealed fixings

TEMPOMATIC TEMPOSTOP
Cross wall electronic urinal valve Cross wall time flow urinal valve

NEW

• Mains supply. • For standard or siphon action urinals.
• Electronic control unit 12V with solenoid valve, • For walls ≤ 200mm.
filter and stopcock M½". • Compatible with rain water.
• For cross wall installation. • Time flow ~3 seconds.
• Shock-resistant infrared presence detection sensor. • Flow rate pre-set at 0.15 L/sec. at 3 bar, can be adjusted.
• Detection distance, time flow and flow rate can be adjusted • Chrome-plated metal body M½".
during installation. • Control base plate with anti-rotating pin.
• We recommend a 230/12V transformer (see below). • Connecting nut.
• Detection delay is 3 seconds. • Threaded rod can be cut to size.
• Automatic pre-rinse is possible. • 30-year warranty.
• Time flow ~3 seconds, can be adjusted from 3 - 12 seconds.
• Hygienic duty flush every 24 hours after last use:
prevents vacuums.
• Flow rate 0.3 L/sec. at 3 bar, can be adjusted.
• Wall plate flush to the wall.
• Threaded rod can be cut to size.
• Compatible with rain water.
• 30-year warranty.

1/2" 110 max 200 max 4
155 max
60 Ø 50
Ø 21 Ø 60 1/2" Ø 21
1/2"
105x105x60
1,5m
130
1/2"

1m
428150 777110

TEMPOMATIC cross wall urinal valve
For walls ≤ 155mm 428150
For walls ≤ 225mm 428200
Transformer 230/12V for 1 - 5 TEMPOMATIC urinals
Without housing 406000
In a waterproof housing 406220 TEMPOSTOP cross wall urinal valve 777110
Alternative cross wall lengths available on request
Alternative cross wall lengths available on request
