/ Electronic shower controls TEMPOMATIC

• Water savings: 80%
• Vandal-resistant: chrome-plated solid brass, cross wall installation, concealed fixings
• Hygiene: no manual contact, anti-bacterial duty flush
• Maintenance: LED diagnostic aids

TEMPOMATIC
Cross wall electronic shower kit

• TEMPOMATIC electronic valve for mixed water supply.
• For walls ≤ 155mm.
• Power supply by electronic control unit with solenoid valve ½".
• 230/12V transformer.
• 2 operation modes:
- automatic activation via presence detection.
- voluntary ON/OFF activation by passing hand
in front of sensor ~10 cm.
• Duty flush (~60 seconds every 24 hours after the last use).
• Adjustable time flow 30 - 60 seconds.
• Flow rate 6 lpm at 3 bar with chrome-plated, tamperproof
ROUND shower head with automatic
flow rate regulation.
• Chrome-plated solid brass.
180 max 35
• Wall plate flush to the wall.
• Threaded rods can be cut to size. 1/2"
• 30-year warranty. Ø 21
1,5m

1/2"

155 max
452159
Ø 60
1,3m
Ø 60 Ø 21 Ø 32
TEMPOMATIC cross wall shower kit
Kit with shower head 452159
Control without shower head 452150
We recommend installing a TMV (see page 143)
and a floor trap (see page 131)

242 Secure sector
