Page 98 - Accessibility-Hygienic-Accessories

/ Shower grab bars

Straight bar with sliding shower head holder

Additional products

Sliding soap dish and shower head
(see pages 104 & 105)

UltraPolish

UltraSatin

• For showers or baths.
• Can be used as a vertical grab bar and shower head riser rail.
• Chrome-plated metal sliding shower head holder with ergonomic locking ring.
• Sliding soap dish can be added (order separately).
• Bacteriostatic 304 stainless steel tube.
• Stainless steel with UltraPolish bright polished finish or UltraSatin polished satin finish,
uniform non-porous surface for easy maintenance and hygiene. 8,5
• Plate welded to the tube by invisible safety bead weld (process exclusive to "ArN-Securit"). Ø 72
• 40mm gap between the bar and the wall:
minimal space prevents the forearm passing between the bar Ø 32
40
and the wall, reducing the risk of fracture in case of loss of balance.
• Concealed fixings, secured to wall by a 3-hole plate, Ø 72mm.
Fixing plates and cover plates in 304 stainless steel. 5460
• Supplied with stainless steel screws for concrete walls.
• Height: 1,150mm, Ø 32mm.
• Tested to over 200kg. Maximum recommended user weight: 135kg.
• 30-year warranty.
• CE marked.
Ø 32

1150

Straight bar Ø 32mm with sliding shower head holder
UltraPolish bright polished stainless steel 5460P2
UltraSatin polished satin stainless steel 5460S
5460
96 Accessibility - Stainless Steel Range
