Page 76 - Accessibility-Hygienic-Accessories

/ Shower grab bars

T-shaped grab bar with sliding vertical riser rail

Additional products

NEW

NEW Sliding shower head
holder, sliding soap
dish and shower shelf
with glove holder
(see page 78)

Metallised
anthracite

Matte
white

Matte
black

• For showers.
• Use as a grab bar and to support the user in an upright position.
• Helps and secures entry and movement in the shower.
• Use as a shower riser rail by adding a sliding shower head holder
and/or a soap dish.
• Upright position can be adjusted during installation:
can be moved to the left or the right in order to adapt the space
(positioning of shower, depth of shower seat...).
• Aluminium tube thickness 3mm. Solid aluminium fixing points.
• Rounded profile Ø 35mm with ergonomic flat front face
that prevents rotation for an optimal grip.
• Choice of powder-coated metallised anthracite (LRV 14), matte white
(LRV 82) or matte black (LRV 5) finish; provides a good visual contrast 38
with the wall.
• Uniform surface for easy maintenance and hygiene.
• 38mm gap between the bar and the wall: Ø 35
minimal space prevents the forearm passing between the bar
and the wall, reducing the risk of fracture in case of loss of balance.
• Concealed fixings.
• Supplied with stainless steel screws Ø 8 70mm for concrete walls. 1185 1130
• Dimensions: 1,130 500mm. Upright can be moved
• Tested to over 200kg. Maximum recommended user weight: 135kg.
• 30-year warranty.
• CE marked.

T-shaped grab bar with sliding vertical riser rail
500
Metallised anthracite powder-coated aluminium 511944C
615
Matte white powder-coated aluminium 511944W
Matte black powder-coated aluminium 511944BK
511944
74 Accessibility - Be-Line range
®
