Page 78 - Accessibility-Hygienic-Accessories
P. 78

/ Shower grab bars


              Two-wall corner grab bar




























                Metallised
                anthracite



                  Matte
                  white


                  Matte
                  black

              • For WCs, showers or baths.                                           Additional product
              • Use as a grab bar and to support the user in an upright position.
              • Helps and secures entry and movement in the shower also with getting
               in and out of the bath.                                                NEW
              • Helps with the transfer from a wheelchair to the toilet seat,
               for WCs with recessed cisterns or direct flush.
              • Aluminium tube thickness 3mm. Solid aluminium fixing points.
              • Rounded profile Ø 35mm with ergonomic flat front face
               that prevents rotation for an optimal grip.
              • Choice of powder-coated metallised anthracite (LRV 14), matte white (LRV 82)
               or matte black (LRV 5) finish; provides a good visual contrast with the wall.
              • Uniform surface for easy maintenance and hygiene.
              • 38mm gap between the bar and the wall:                               Shower shelf with glove holder
               minimal space prevents the forearm passing between the bar
                                                                                     (see page 78)
               and the wall, reducing the risk of fracture in case of loss of balance.
              • Concealed fixings.
              • Supplied with stainless steel screws Ø 8   70mm for concrete walls.
              • Dimensions: 695   695mm.
              • Tested to over 200kg. Maximum recommended user weight: 135kg.
              • 30-year warranty.
              • CE marked.

                                                                                                     750
                                                                                                    695
                                                                                                      565
                                                                                                            38
                                                                                                        35



                                                                                          750  695

              Two-wall corner grab bar
              Metallised anthracite powder-coated aluminium               511941C
              Matte white powder-coated aluminium                         511941W
              Matte black powder-coated aluminium                         511941BK
                                                                                                  511941
