Page 77 - Accessibility-Hygienic-Accessories

Shower grab bars /

L-shaped grab bar

Additional products

NEW

NEW Sliding shower head
holder, sliding soap
ACCESSIBILITY BE-LINE ®
dish and shower shelf
with glove holder
(see page 78)

Metallised
anthracite

Matte
white

38
Matte
black 35
750 805 750 805
• For showers or baths.
• Helps the user stand and move safely in the shower or bath.
• Use as a shower rail by adding a sliding shower head holder and/or a soap dish.
• Can be installed with the upright to the left or the right.
• Aluminium tube thickness 3mm. Solid aluminium fixing points.
• Rounded profile Ø 35mm with ergonomic flat front face 450
that prevents rotation for an optimal grip. 505
• Choice of powder-coated metallised anthracite (LRV 14), matte white (LRV 82)
or matte black (LVR 5) finish; provides a good visual contrast with the wall. 511970
• Uniform surface for easy maintenance and hygiene.
• 38mm gap between the bar and the wall:
minimal space prevents the forearm passing between the bar
and the wall, reducing the risk of fracture in case of loss of balance.
38
• Concealed fixings.
• Supplied with stainless steel screws Ø 8 70mm for concrete walls.
• Dimensions: 1,130 or 750 450mm. 35
• Tested to over 200kg. Maximum recommended user weight: 135kg.
• 30-year warranty.
• CE marked.
1130 1185 1130 1185
L-shaped grab bar - Metallised anthracite
Metallised anthracite powder-coated aluminium - H. 750mm 511970C
Metallised anthracite powder-coated aluminium - H. 1,130mm 511971C
L-shaped grab bar - Matte white
Matte white powder-coated aluminium - H. 750mm 511970W
Matte white powder-coated aluminium - H. 1,130mm 511971W
L-shaped grab bar - Matte black 450
505
Matte black powder-coated aluminium - H. 750mm 511970BK
Matte black powder-coated aluminium - H. 1,130mm 511971BK
511971
®
Accessibility - Be-Line range 75
