/ Spare Parts Spout outlets, spouts, hand sprays

SPOUT OUTLETS

Scale-resistant aerators with brass collar
F22 100 (5 per pack) 22.5P A
M24 100 (5 per pack) 24.5P B
M28 100 (2 per pack) 28.2P -
A B
Scale-resistant and tamperproof aerators with eco washer
F22 100 (2 per pack) 925622.2P A
M24 100 (2 per pack) 925624.2P B
BIOSAFE outlets (free flow outlets with no grid or partitions in contact with the water) with brass collar
F22 100 (1 per pack) for basin taps / mixers 5 lpm 923022 -
F22 100 (50 per pack) for basin taps / mixers 5 lpm 923022.50P -
C D M24 100 (1 per pack) for basin taps / mixers 5 lpm 923024 C
M24 100 (50 per pack) for basin taps / mixers 5 lpm 923024.50P C
Hygienic flow straighteners (star-shaped with no grid: reduces bacterial development) with brass collar
F22 100 (2 per pack) 921022.2P -
F22 100 (50 per pack) 921022.50P -
M24 100 (2 per pack) 921024.2P D
E F M24 100 (50 per pack) 921024.50P D
Flow straighteners at 3 lpm (flow rate can be adjusted via 2.5mm Allen key) with brass collar
F22 100 (2 per pack) 922022.2P E
M24 100 (2 per pack) 922024.2P -
Adjustment key (2.5mm Allen key) C282025 F
Filters flat washer filter in Nylon, 0.5mm mesh
For ½" nut (10 per pack) 60212.10P G
G
For ¾" nut (10 per pack) 60234.10P G
Connectors
2 connectors with non-return valves, FM⅜" C151AH75 -
2 connectors with non-return valves, FM½" C291AH75 -

SPOUTS
300
300
Spouts L. 300mm
Over spout Ø 22mm, H. 235mm
230
130 with ¾" nut and star-shaped brass flow straightener 963300245G -
3/4" 3/4" Over spout Ø 22mm, H. 230mm
H I
with ¾" nut and star-shaped flow straightener 963300245F H
200
Over spout Ø 22mm, H. 130mm
200 with ¾" nut and star-shaped flow straightener 963300145F I
Spouts L. 200mm
230 Over spout Ø 22mm, H. 230mm
135
with ¾" nut and flow straightener regulated at 3 lpm 963200245F J
3/4" 3/4"
J K Over spout Ø 22mm, H. 135mm
with ¾" nut and star-shaped flow straightener 963200145F K
150 Under spout Ø 22mm, H. 117mm
3/4"
with ¾" nut and star-shaped brass flow straightener 943200110 L
105 Spout L. 150mm
200
3/4" Over spout Ø 22mm, H. 105mm
L M with ¾" nut and flow straightener regulated at 3 lpm 963150125F M
Over spout Ø 22mm, H. 100mm
with ¾" nut and BIOSAFE outlet 963150923F -
3/4"
Universal telescopic spouts
135 Spout L. 200 - 290mm
with ¾" nut and star-shaped flow straightener 966230 N
200-290
Spout L. 300 - 470mm
N
with ¾" nut and star-shaped flow straightener 966380 -
HAND SPRAYS

For pre-rinse sets Repair kit Type
Nozzle for white hand spray 433000 433305 -
Nozzle for black hand spray 433010 433315 -

88 Spare parts
