/ Non-contact controls Foot or knee-operated

TEMPOGENOU MIXFOOT/MONOFOOT
Knee-operated time flow basin valve Foot-operated basin mixer/valve with instant shut-off

• Time flow ~7 seconds. • Instant automatic shut-off.
• Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 - 6 lpm. • Pedal can be raised for cleaning the floor.
• Reinforced control lever. • Adjustable pedal height.
• Solid brass wall plate with reinforced fixing via 4 stainless steel screws • Fixed by 4 screws.
on the in-line model. • Filters.
• Cold or mixed water supply. • Pre-set mixing can be adjusted on the MIXFOOT mixer version:
• Chrome-plated brass body. half-open for cold water and fully open for mixed water
• 30-year warranty. (pedal touching the floor).
• Available for floor or wall-mounting.
• 30-year warranty.

30
1/2" 1/2"
Ø 80
280
1/2"
435
735400 739100

Ø 15
37
1/2"
Ø 70
Ø 15
440 300
73544715 736102

35
1/2"
Ø 50
440 1/2"

734100
MIXFOOT mixer
Floor-mounted, M½" 739100
TEMPOGENOU valve Wall-mounted, M½" 739102
Straight for in-line inlet, stud nut 735000 MONOFOOT valve
Straight for in-line inlet, M½" 735400 Floor-mounted, stud nut Ø 14mm 736001
Straight for in-line inlet Ø 15mm compression fittings 73544715 Floor-mounted, M½" 736101
Angled for recessed inlet, M½" 734100 Wall-mounted, M½" 736102
We recommend installing a TMV (see page 84) We recommend installing a TMV (see page 84) with the MONOFOOT valve
Option: spouts (see opposite) Option: spouts (see opposite)

60 Non-contact controls
