Safety showers Eye wash and shower combination /


                     •  Effective: large flow rates for rapid decontamination
                     •  Frost-free protection: frost-free system as standard, riser column and shower head drain
                     •  Comfort: quick and easy to activate, gentle spray for users




            Eye wash and shower combination
            Free-standing
                                                                 • Frost-free system as standard.
                                                                 • 304 stainless steel basin Ø 250mm with green finish.
                                                                 • Eye wash spray heads fitted with protective caps in shock-resistant,
                                                                  green ABS. Caps eject automatically when eye wash is activated.
                                                                 • Flow rate 20 lpm at 3 bar dynamic pressure, aerators with stainless
                                                                  steel double filters.
                                                                 • Circular shower head Ø 250mm in green, shock-resistant ABS.
                                                                 • Flow rate 96 lpm at 3 bar dynamic pressure.
                                                                 • Water supply F1".
                                                                 • Pipes made from galvanised steel, grey powder-coated finish.
                                                                  Triangular pull handle in green powder-coated brass.
                                                                  Hand and foot controls in green powder-coated galvanised steel.
                                                                 • Fixed to the floor by a brass plate (screws not included).
                                                                 • Supplied with identification signs for first aid equipment:
                                                                  "Safety Shower" and "Safety Eye Wash".
                                                                 • 30-year warranty.

                                                                 Operation:
                                                                 ¼-turn, nickel-plated brass valves open and close quickly.
                                                                 Simultaneous eye wash and shower:
                                                                 • Water flows simply by pulling on the triangular handle.
                                                                    The flow will continue even when the handle is released.
                                                                 • The flow will stop when the handle is returned to its original position.
                                                                 Eye wash only:
                                                                 • Water flow is operated by the foot pedal or the hand control.
                                                                  The eye wash will continue to flow when the pedal or hand control
                                                                  is released.
                                                                 • The water flow will stop when the hand control is pulled towards
                                                                  the user or the foot pedal is raised.
                                                                 The water does not shut off automatically, allowing the injured person
                                                                 to have both hands free (to remove their clothing, keep their eyes open, etc.).
                                                                                                    Ø 250
                                                                                                         200 x 200
                                                                                  450



                                                                                  660

                                                                                   200 x 200


                                                                                                 140
                                                                                    Ø 250
                                                                       2115


                                                                                  1"1/4

                                                                                                                          SAFETY CONTROLS
                                                                                                1050
                                                                                       230




                                                                                              1"
                                                                                         9203
                                                                  Eye wash and shower combination            9203
                                                                  We recommend installing a TMV (see page 143)
