Electronic direct flush systems TEMPOMATIC Connect /

• Efficiency and water savings: direct flush reduces the risk of leaks, powerful flush is available instantly
• Hygiene: touch-free automatic flush, no cistern: no water stagnation (reduces bacterial development)
• Comfort: touch-free automatic flush
• Easy to install: modular and adjustable waterproof housing or on frame system

TEMPOMATIC Connect TEMPOFIX 3 with TEMPOMATIC Connect
Recessed electronic direct flush valve Frame system with electronic flush valve
186x186
NEW NEW 3/4"

1000-1320

180-230
350
10-120
• Cistern-less flush system: directly connected to pipework.
• Battery-operated with CR123 Lithium 6V batteries or 230/6V mains
supply (cable and transformer supplied).

• Satin stainless steel control plate 186 186mm.
• Waterproof recessing housing:
- Collar with waterproof seal.
- Hydraulic connection from the outside and maintenance from the front.
- Adjusts to all types of installation (rails, solid walls, panels).
- Compatible with wall finishes 10 - 120mm
(while maintaining the minimum recessing depth of 93mm).
- Suitable for standard or "pipe-in-pipe" supply.
- Stopcock and flow rate adjustment, activation and electronic unit
are all integrated and accessible from the front. 300-620
- TEMPOMATIC F¾" flush valve is compatible with sea water, rain water
and grey water. 165
- Vacuum breaker inside the housing. 157-177
- Supplied in 2 kits: secure system flush without sensitive elements. 564005 + 465000
• Shock-resistant infrared presence detection sensor.
• Detection delay is 10 seconds. • Black powder-coated steel frame. CISTERN-LESS WCs
• Touch-free automatic activation when the user leaves • Frame height can be adjusted from 0 - 200mm (with 1m mark).
or voluntary touch-free (when hand is moved 4cm from the sensor). • Ø 32mm flush tube with Ø 55mm connection washer.
• "Intelligent" automatic rinsing: flush volume adapts according to use. • ABS soil pipe Ø 100mm outlet with waterproof seal,
• Hygienic duty flush, every 24 hours (can be adjusted to 12 hours or OFF) with 2 setting positions.
after the last use. • Delivered pre-mounted.
• Bluetooth setting with the DELABIE Connect app. • Compatible with solid wall finishes from 10 - 120mm.
®
• Outlet connection for PVC tube Ø 26/32mm. • 30-year warranty.
• Base flow rate: 1 L/sec. at 1 bar dynamic pressure.
• Suitable for rimless pans without flow rate regulation Available in 2 versions:
and suitable for people with reduced mobility. Self-supporting frame system with large feet to fix to load-bearing floors.
• 30-year warranty. 225 93-190 Wall-mounted frame system to fix to load-bearing walls.
186x186
3/4"
Fitted with TEMPOMATIC Connect electronic flush valve (see opposite).
Provisional availability: 1 half 2025.
st
150 Please contact the sales office to check availability.
TEMPOFIX 3 WC frame system with TEMPOMATIC Connect
564065
Self-supporting frame system - 6V battery-operated
+ 465006
464SBOX + 465000 564005
st
Provisional availability: 1 half 2025. Self-supporting frame system - 230/6V mains supply
+ 465000
Please contact the sales office to check availability.
564060
TEMPOMATIC Connect WC recessed in waterproof housing Wall-mounted frame system - 6V battery-operated
+ 465006
464PBOX
6V battery-operated 564000
+ 465006 Wall-mounted frame system - 230/6V mains supply
+ 465000
464SBOX
230/6V mains supply For Ø 90mm (or 110mm) soil pipe outlet versions: add "BE" (or "DE") after
+ 465000 the reference for kit 1
We recommend a flush tube (see page 234) Options: wall fixings, sleeve connector and kit for disabled WC (see page 235)
Cistern-less WCs 211
