/ Electronic direct flush systems TEMPOMATIC dual control

TEMPOMATIC DUAL CONTROL RECESSED:
100% WATERPROOF RECESSED HOUSING, MODULAR AND ADAPTABLE

Modular 100% waterproof
Attaches via the sides, front or back, DELABIE's recessed housing Standard housings on the market are designed to be cut to size flush
can be used on plasterboard rails, on load-bearing walls or even to the wall, which increases the risk of leaks between the wall
thin panels, the installation is therefore modular, adapting to the type and the collar.
of project. DELABIE's recessed housing is equipped with a collar with an
integrated seal, that clips onto the housing once the wall finish
is in place (patented system). It is completely waterproof
without silicone. Any condensation is evacuated via the plate.
The wall stays intact throughout.

Plasterboard rails Solid walls Panels

Adaptable
The collar can be positioned to allow the housing to be cut to size
lengthwise depending on the wall thickness whilst still guaranteeing Collar with integrated waterproof seal
complete waterproofing. Thin or thick, the housing adapts to all the
requirements of walls from 10 to 120mm. Resistant to intensive use and vandalism
The control plate, made from satin finish stainless steel will withstand
even the most extreme handling. Its fixings are concealed and its
streamlined design prevents unwanted removal.
To prevent abuse or waste in the voluntary mode, the TEMPOMATIC
dual control is fitted with an AB anti-blocking system. This security
feature prevents the valve from being blocked in the open position.
The flush takes place only when the push-button is released.

Minimal servicing and simple to maintain
Maintenance is carried out from the front by simply removing
Thick wall finish Narrow wall finish the control plate. The technical elements are accessible
Max. 120mm Min. 10mm
and spare parts come pre-assembled.
An LED indicates when the batteries need to be replaced.
Quick and easy to install Integrated in the plate, they can be replaced without shutting off
The TEMPOMATIC dual control can be connected to a standard the water or removing the valve.
"pipe-in-pipe" supply. The hydraulic connection is made from the The vacuum breaker is located inside the housing.
outside of the housing. In case of backflow, the water will evacuate in front of the wall
During the installation, the electronic unit is replaced by a temporary via the housing, and not behind (or into) the wall.
cap to flush the system safely, without damaging the technical The TEMPOMATIC dual control is suitable for grey water,
elements. rain water and sea water.
Making protection from frost and in-depth maintenance easier,
the valve can be disconnected and removed from the inside,
without removing the housing.
Electronic unit
Hygiene
The TEMPOMATIC dual control flush can be activated voluntarily via
the push-button, or automatically when the user leaves. This dual
control guarantees permanent hygiene for the WC pan,
Temporary cap even if the user forgets or neglects to flush the WC. The duty flush
prevents bacterial proliferation and ensures that the pipework
is flushed every 24 hours when not in use.
Water savings Design
DELABIE has developed an "intelligent" rinse function The TEMPOMATIC dual control plate has a timeless design, available
in the automatic mode. The system can distinguish between in satin finish stainless steel with a chrome-plated metal push-
the need for a short rinse (2 to 3 litres) or a longer flush (4 to 6 litres). button. Thanks to its sleek lines, it fits perfectly in any type of public
and commercial building. Its smooth surface limits the build-up of
dirt and facilitates cleaning. This new concept combines design and
functionality: the electronics are integrated directly in the control plate.

206 Cistern-less WCs
