/ Electronic urinal valves TEMPOMATIC 4 recessed

TEMPOMATIC 4 RECESSED:
100% WATERPROOF RECESSED HOUSING, MODULAR AND ADAPTABLE

Modular 100% waterproof
Attaches via the sides, front or back, DELABIE's recessed housing Standard housings on the market are designed to be cut to size flush
can be used on plasterboard rails, on load-bearing walls to the wall, which increases the risk of leaks between the wall
or even thin panels, the installation is therefore modular, adapting to and the collar.
the type of project. DELABIE's recessed housing is equipped with a collar with an
integrated seal, that clips onto the housing once the wall finish
is in place (patented system). It is completely waterproof
without silicone. Any condensation is evacuated via the plate.
The wall stays intact throughout.

Plasterboard rails Load-bearing walls Thin panels

Adaptable
The collar can be positioned to allow the housing to be cut to size
lengthwise depending on the wall thickness whilst still guaranteeing Collar with integrated waterproof seal
complete waterproofing. Thin or thick, the housing adapts to all the
requirements of walls from 10 to 120mm.
Minimal servicing and simple to maintain
Maintenance is carried out from the front by simply removing
the control plate.
The technical elements are accessible and spare parts come
pre-assembled. An LED indicates when the batteries need to be
replaced. Integrated in the plate, they can be replaced without
shutting off the water or removing the valve.
The TEMPOMATIC 4 is suitable for grey water, rain water and sea water.
Making protection from frost and in-depth maintenance easier,
the valve can be disconnected and removed from the inside,
Thick wall finish Narrow wall finish
Max. 120mm Min. 10mm without removing the housing.
Water savings
Quick and easy to install Thanks to its optimised flow rate and time flow, the TEMPOMATIC 4
The TEMPOMATIC 4 can be connected to a standard "pipe-in-pipe" rinse provides just the necessary flush volume and, therefore,
supply. the best compromise between water consumption and efficacy.
The hydraulic connection is made from the outside of the housing. It also features the high-frequency mode.
During the installation, the solenoid valve, filter and stopcock are For more information see page 161.
replaced by a temporary casing to facilitate and ensure a safe system
flush, without damaging the technical elements. Hygiene
The TEMPOMATIC 4 recessed urinal flush rinses automatically after
each user leaves. No manual contact prevents the spread of germs
by hand. The hygienic duty flush prevents bacterial proliferation
Definitive valve
and the problem of vacuums.
The TEMPOMATIC 4 is supplied with a reduced-stagnation solenoid
valve. For more information see page 161.

Design
The TEMPOMATIC 4 control plate has a timeless design, available
in bright polished, satin or black glass.
Temporary casing Compact and discreet, it fits perfectly in any type of public
and commercial building. Its smooth surface limits the build-up
of dirt and facilitates cleaning.
This new concept combines design and functionality:
the electronics are integrated directly in the wall plate.

166 Urinals
