Electronic urinal valves TEMPOMATIC 4 /

• Water savings: high-frequency mode, 3 available programmes
• Hygiene: systematic individual rinsing with no manual contact, hygienic duty flush, reduced-stagnation solenoid valve
• Easy to install: modular and adjustable waterproof housing (for walls and finishes)
• Easy to replace the batteries: after 3 - 6 years, without removing the urinal valve or shutting off the water

TEMPOMATIC 4
Recessed electronic urinal valve

• Battery-operated with CR123 6V Lithium batteries
or 230/6V mains supply (cable and transformer supplied). URINALS
• Control plate 145 145mm with integrated electronics. 175 83 - 190
• Waterproof recessing housing: 1/2"
- Collar with waterproof seal. 145 x 145
- Hydraulic connection from the outside and maintenance from the front.
- Adjusts to all types of installation (rails, solid walls, panels).
- Compatible with wall finishes 10 - 120mm 150
(while maintaining the minimum recessing depth of 83mm).
- Suitable for standard or "pipe-in-pipe" supply. 200
- Stopcock and flow rate adjustment, filter and solenoid valve
Ø35
are all integrated and accessible from the front.
- TEMPOMATIC 4 F½" urinal valve is compatible with sea water,
rain water and grey water.
- Supplied in 2 kits: secure system flush without sensitive elements. 430PBOX + 430016 + 752430
• Shock-resistant infrared presence detection sensor.
• Detection delay is 10 seconds.
• 3 programmes (rinse volume can be set according to urinal type).
• High-frequency mode (exclusive to DELABIE):
- Short rinse after each user.
- Additional rinse at the end of the busy period.
• Hygienic duty flush every 24 hours (can be adjusted to 12 hours or OFF)
after the last use: prevents vacuums. TEMPOMATIC 4 recessed urinal valve in a waterproof housing
• Flow rate pre-set at 0.15 L/sec. at 3 bar, can be adjusted. Bright polished finish stainless steel 430PBOX
• Connection with Ø 35mm connection washer (for standard urinals) 6V battery-operated + 430016
or ½" brass connection (for urinals supplied by flexible). Bright polished finish stainless steel 430SBOX
• For use with neck tube ref. 752430 or 757430. 230V mains supply + 430010
• Suitable for people with reduced mobility. Satin finish stainless steel 430PBOX
• 30-year warranty. 6V battery-operated + 430006
Satin finish stainless steel 430SBOX
230V mains supply + 430000
Black tempered glass finish 430PBOX
6V battery-operated + 430036
Black tempered glass finish 430SBOX
230V mains supply + 430030
SELECTION Ø 35mm neck tube supply for urinals 752430
miaw Neck tube supply for urinals with flexible ½" 757430
