/ Time flow direct flush system TEMPOFLUX 3

TEMPOFLUX 3 RECESSED:
100% WATERPROOF RECESSED HOUSING, MODULAR AND ADAPTABLE

Modular 100% waterproof
Attaches via the sides, front or back, DELABIE's recessed housing Standard housings on the market are designed to be cut to size flush
can be used on plasterboard rails, on load-bearing walls to the wall, which increases the risk of leaks between the wall
or even thin panels, the installation is therefore modular, adapting and the collar.
to the type of project. DELABIE's recessed housing is equipped with a collar with an
integrated seal, that clips onto the housing once the wall finish
is in place (patented system).
It is completely waterproof without silicone. Any condensation
is evacuated via the plate. The wall stays intact throughout.

Plasterboard rails Load-bearing walls Panels

Adaptable
The collar can be positioned to allow the housing to be cut to size
lengthwise depending on the wall thickness whilst still guaranteeing
complete waterproofing. Thin or thick, the housing adapts to all the Collar with integrated waterproof seal
requirements of walls from 10 to 120mm.
Resistant to intensive use and vandalism
The control plate, made from satin finish stainless steel will withstand
even the most extreme handling. Its fixings are concealed
and its streamlined design prevents unwanted removal.
To prevent abuse or waste, the TEMPOFLUX 3 is fitted
with an AB anti-blocking system. This security feature prevents
the valve from being blocked in the open position. The flush takes
place only when the push-button is released.
Minimal servicing and simple to maintain
Thick wall finish Narrow wall finish Maintenance is carried out from the front by simply removing
Max. 120mm Min. 10mm
the control plate. The technical elements are accessible
and spare parts come pre-assembled.
Quick and easy to install The flush volume can be adjusted directly behind the control plate,
The TEMPOFLUX 3 can be connected to a standard "pipe-in-pipe" without shutting off the water supply or removing the valve.
supply. The hydraulic connection is made from the outside of The vacuum breaker is located inside the housing.
the housing. In case of backflow, the water will evacuate in front of the wall
During installation, the cartridge is replaced by a temporary cap via the housing, and not behind (or into) the wall.
to flush the system safely, without damaging the technical elements. The TEMPOFLUX 3 is suitable for grey water, rain water
and sea water.
Cartridge Making protection from frost and in-depth maintenance easier,
the valve can be disconnected and removed from the inside,
without removing the housing.

Comfort
Thanks to its soft-touch operation, the TEMPOFLUX 3 can be used
by all users (children, the elderly or people with reduced mobility).
Temporary cap
The acoustic level is low and complies with European standard
EN 12541 class II.
Water savings
The TEMPOFLUX 3 with 3L/6L dual flush optimises flushing Design
and water consumption. The flush volume can be adjusted to 2L/4L, The TEMPOFLUX 3 control plate has a timeless design available
to achieve the highest standards for environmental labels. in 3 finishes: satin finish stainless steel, chrome-plated metal
For more information see page 8. or black glass.
The AB anti-blocking device controls the flush volume regardless of Thanks to its sleek lines, it fits perfectly in any type of public
how long the push-button is pressed for. or commercial building. Its smooth surface limits the build-up of dirt
and facilitates cleaning.
