/ Time flow shower controls TEMPOSOFT 2

• Water savings: 80%
• Comfort: soft-touch operation

TEMPOSOFT 2 TEMPOSOFT 2 TEMPOSOFT 2
Time flow valve for panels Recessed time flow valve Exposed time flow valve

• TEMPOSOFT 2 M½" time flow valve • TEMPOSOFT 2 M½" time flow valve • TEMPOSOFT 2 M½" time flow valve
for mixed water supply. for mixed water supply. for mixed water supply.
• For panels or dry walls 7mm max. • For recessed installation. • For wall-mounted exposed installation.
• Soft-touch operation. • Bright polished 304 stainless steel wall plate • Soft-touch operation.
• Time flow ~30 seconds. Ø 130mm. • Time flow ~30 seconds.
• Flow rate pre-set at 6 lpm at 3 bar, • Spacing can be adjusted from 1 – 5mm. • Flow rate pre-set at 6 lpm at 3 bar,
can be adjusted. • Soft-touch operation. can be adjusted.
• Chrome-plated brass body. • Time flow ~30 seconds. • Chrome-plated brass body.
• Suitable for people with reduced mobility. • Flow rate pre-set at 6 lpm at 3 bar, • Suitable for people with reduced mobility.
• 30-year warranty. can be adjusted. • 30-year warranty.
• Chrome-plated brass body.
This model does not have a waterproof • Suitable for people with reduced mobility.
recessing housing. The installer must ensure • 30-year warranty.
that the recessing area is waterproof
and any leaks or condensation can drain away This model does not have a waterproof
(see installation guide). recessing housing. The installer must ensure 34
1/2"
that the recessing area is waterproof
and any leaks or condensation can drain away
(see installation guide). 70
1/2"
Ø 48

Ø 130 747800
1/2"
1/2"
7 max
34
70 70 1/2"
35
1/2"
1/2" 24
5 max Ø 48
62
749870 749428 748800

TEMPOSOFT 2 exposed valve
Straight for in-line inlets 747800
TEMPOSOFT 2 valve for panels 749870 TEMPOSOFT 2 recessed valve 749428 Angled for recessed inlets 748800
We recommend installing a TMV (see page 143) We recommend installing a TMV (see page 143) We recommend installing a TMV (see page 143)
and a floor trap (see page 131) and a floor trap (see page 131) and a floor trap (see page 131)
Option: shower heads (see page 134) Option: shower heads (see page 134) Option: shower heads (see page 134)

126 Showers
