Page 126 - Water_Controls_for_Public-Commercial

/ Time flow shower controls TEMPOMIX

• Water savings: 80%
• Comfort: temperature selection directly via the single control mixer, soft-touch operation
• Vandal-resistant: chrome-plated solid brass, concealed fixings

TEMPOMIX TEMPOMIX
Cross wall time flow shower kit Exposed time flow shower mixer

• TEMPOMIX ¾" single control mixer. • TEMPOMIX ¾" single control mixer.
• For walls ≤ 220mm. • For wall-mounted, exposed installation.
• Temperature control and operation via the push-button. • Temperature control and operation via the push-button.
• Maximum temperature limiter (can be adjusted by the installer). • Maximum temperature limiter (can be adjusted by the installer).
• Ligature-resistant collar. • Soft-touch operation.
• Soft-touch operation. • Time flow ~30 seconds.
• Time flow ~30 seconds. • Flow rate 12 lpm at 3 bar, can be adjusted.
• Flow rate 6 lpm at 3 bar, comfort rain effect. • Chrome-plated brass body.
• Chrome-plated, tamperproof ROUND shower head • Integrated filters and non-return valves.
with automatic flow rate regulation. • Chrome-plated metal push-button.
• Chrome-plated brass valve body and shower head. • Available with or without elbow unions.
• Integrated filters and non-return valves. • 30-year warranty.
• Chrome-plated metal push-button.
• Threaded rods can be cut to size.
• 30-year warranty.
30 30
3/4" 3/4"
1/2" 230 max 35
3/4"
3/4"
Ø 21
790874 790000
30 120 min 220 max 55
Ø 70
Ø 21
45
TEMPOMIX exposed mixer
3/4" With elbow unions 150mm centres 790874
With in-line unions 90mm centres 790000
796209 For panels 1 - 10mm 790970
Reinforced wall plate Ø 80mm. 824800
TEMPOMIX cross wall shower kit 796209 Recommended for installing on panels or dry walls
We recommend installing a floor trap (see page 131) We recommend installing a floor trap (see page 131)
Other cross wall lengths available on request (minimum order of 200 units) Option: shower heads (see page 134)

124 Showers
