/ Time flow shower valves TEMPOMIX 3 recessed

TEMPOMIX 3 RECESSED:
100% WATERPROOF RECESSED HOUSING, MODULAR AND ADAPTABLE

Modular 100% waterproof
Attaches via the sides, front or back, DELABIE's recessed housing Standard housings on the market are designed to be cut to size flush
can be used on plasterboard rails, on load-bearing walls to the wall, which increases the risk of leaks between the wall
or even thin panels, the installation is therefore modular, adapting and the collar.
to the type of project. DELABIE's recessed housing is equipped with a collar with
an integrated seal, that clips onto the housing once the wall finish
is in place (patented system). It is completely waterproof without
silicone. Any condensation is evacuated via the plate.
The wall stays intact throughout.

Plasterboard rails Load-bearing walls Thin panels

Adaptable
The collar can be positioned to allow the housing to be cut to size
lengthwise depending on the wall thickness whilst still guaranteeing
a waterproof seal. Thin or thick, the housing adapts to all the
requirements of walls from 10 to 120mm. Collar with integrated waterproof seal

Resistant to intensive use and vandalism
A solid brass body, shock-resistant mechanisms, a chrome-plated
metal plate, the TEMPOMIX 3 will withstand even the most extreme
handling. Its fixings are concealed. Its streamlined design prevents
unwanted removal.

Minimal servicing and simple to maintain
Maintenance is carried out from the front by simply removing
Thick wall finish Narrow wall finish the control plate.
Max. 120mm Min. 10mm The technical elements are accessible and spare parts come pre-
assembled. Making protection from frost and in-depth maintenance
easier, the valve can be disconnected and removed from the
Quick and easy to install inside, without removing the housing.
The TEMPOMIX 3 can be connected to a standard "pipe-in-pipe" supply.
The hydraulic connection is made from the outside of the housing. 85% water savings
During installation, the time flow cartridge, filters and non-return Shut-off is automatic after ~30 seconds of flow. DELABIE's time
valves are replaced by temporary caps to flush the system safely, flow controls remove any risk of waste through negligence.
without damaging the technical elements. The flow time is reduced to the necessary minimum (wetting, rinsing).
The flow rate is regulated at 6 lpm regardless of pressure variations
in the system.
Cartridge, filters
and non-return valves
Soft-touch operation
Soft technology allows all users (children, the elderly or people
with reduced mobility) to use the controls with no effort.
The TEMPOMIX 3 requires half the effort to operate compared
to a conventional shower control.
Temperature limitation and selection
Users can choose the temperatures themselves. The selection
Temporary caps
is made via the single control push-button.
The mixer is supplied with a pre-set maximum temperature limiter
which can be adjusted during installation. The user cannot increase
the temperature above the maximum set temperature, reducing
any risk of scalding.

118 Showers
