Point-of-use filters Taps and wall-mounted showers /

BIOFIL tap and wall-mounted shower filter
Anti-Legionella and all-germ filter

Related products

Push-fit connector
• Simple to connect to the
point-of-use requiring
treatment, no tools required.
• Standard or vandal-resistant
versions available.

24x100 24x100 22x100 22x100
25 25 23 24
Ø 3 Ø 3
Ø 26 Ø 31 Ø 26 Ø 31
820124N 821124 820122N 821122
• Single use filter for taps and wall-mounted showers, sterilising grade 0.1µm nominal-rated.
• Hydrophilic polyethylene hollow fibres. 1/2" 1/2" 24x125 24x125
• Maximum lifespan: 2, 3 or 4 months after installation depending on the model installed.
• Space saving, suitable for mixers and taps with a low drop height. 25 26 Ø 3 25 28 Ø 3
• Volume of water filtered per duration of use: 6,000L for 2 months; 9,000L for 3 months;
Ø 26 Ø 31 Ø 26 Ø 31
12,000L for 4 months.
• Filtration flow rate: 5.5 lpm* at 3 bar for 2-month versions; 7.6 lpm* at 3 bar for 3 and 4-month 820123 821123 820125 821125
versions (filter only, excludes any flow rate restrictor/regulator in the shower or mixer).
• Maximum upstream pressure at point-of-use: 5 bar. 16,5x100
• Careful management of retro-contamination: protective skirt and filter position Vandal-resistant version:
21 Tamper-proof connector
is optimised thanks to a tilted connector. prevents vandalism and
• Compatible with and resistant to chemical and thermal shocks. Ø 26 unauthorised removal of filter.
• CE marked class I Medical Device for non-sterile versions.
• CE marked class Is Medical Device for sterile versions. 820126N
• Available in two versions:
- sterile filters, individually wrapped in sterile packaging; Push-fit connector for mixer/tap filters
- non-sterile filters, individually wrapped in non-sterile packaging. M24 100 820124N
* Average flow rate during the product lifespan.
M24 100, vandal-resistant version 821124
F22 100 820122N
Tilted connector to optimise
filter position: F22 100, vandal-resistant version 821122
Filter position can be adjusted to prevent M½" 820123
the water flowing directly onto the waste.
Reduces the risk of retro-contamination. shower spray laminar flow M½", vandal-resistant version 821123
M16.5 100 820126N
Ø 11
Ø11 Push-fit connector for wall-mounted shower filters
Ø 11
M24 125 820125
79 M24 125, vandal-resistant version 821125
60 66 63
44 50 These connectors are suitable for use with the new range of filters
shown opposite.
Ø 56 Ø 56 Ø 56
20250/30250 20350/30350 20450/30450
20251/30251 20351/30351 20451/30451
1 BIOFIL tap and wall-mounted shower filter*
2-month lifespan
Sterile, shower spray 20250
Sterile, laminar flow 20251
Non-sterile, shower spray 30250
Non-sterile, laminar flow 30251
3-month lifespan
Sterile, shower spray 20350
Sterile, laminar flow 20351
Non-sterile, shower spray 30350
Non-sterile, laminar flow 30351
4-month lifespan
Sterile, shower spray 20450
Sterile, laminar flow 20451
Non-sterile, shower spray 30450
Non-sterile, laminar flow 30451
* Reference is for a single unit. Can only be ordered in multiples of 10 (packaged in boxes of 10).
