Mirror  Soap  Water  Air





 T E C H N I C A L   D E S C R I P T I O N


 4 FUNCTION MIRROR CABINET
 MIRROR, SOAP DISPENSER, TAP AND HAND DRYER
 OR PAPER TOWEL DISPENSER







 304 stainless steel designer cabinet    Liquid or foam electronic soap dispenser:  Models with paper towel dispenser:  4-in-1 mirror cabinets
 with matte black melamine finish.  - No-waste pump dispenser.  - Dispenses one sheet at a time.
                   510203    L. 600mm - Mirror, soap, water, hand dryer
 - Large capacity tank: 5 litres.  - Dimensions: 120 x 275 x 360mm.
 Touch-free for improved hygiene:    -  Suitable for vegetable-based liquid soap   - Capacity: 500 sheets.  510204  L. 800mm - Mirror, soap, water, hand dryer
 soap dispenser, tap and hand dryer    with a maximum viscosity of 3,000 mPa.s   510205  L. 600mm - Mirror, soap, water, paper towel dispenser
 are automatically activated when hands   or specific foam soap.  510206  L. 800mm - Mirror, soap, water, paper towel dispenser
 are detected by infrared sensor.  LED strip downlights for the basin.
                   3-in-1 mirror cabinets
 Electronic basin tap:
 Quick and easy to install:  Vandal-resistant model with lock
 - Reduced stagnation solenoid valve.  and standard DELABIE key.  510207  L. 600mm - Mirror, soap, hand dryer
 -  A single electrical connection for all
 the elements: 230V / 50-60Hz mains supply.  -  Flow rate pre-set at 3 lpm at 3 bar,    510208  L. 800mm - Mirror, soap, hand dryer
 adjusts from 1.4 to 6 lpm.  Anti-blocking: stops automatically
 -  Connects to the water supply inside    510209  L. 600mm - Mirror, soap, paper towel dispenser
 the cabinet via top or recessed inlets.  - Scale-resistant flow straightener.  if the soap dispenser, tap or hand dryer    510210  L. 800mm - Mirror, soap, paper towel dispenser
 - Water connection: M3/8".  -  Duty flush (~60 seconds every 24 hours   are used continuously.
 after the last use).  Units for installation behind a mirror
 -  Concealed fixings: supplied with    Internal storage shelf.
 stainless steel screws for concrete walls    - Stopcock.  510203I  3-in-1 unit: soap, water, hand dryer
 or reinforced wood.  -  For mixed water, use a PREMIX mixer.
 Several cabinets can be installed    510205I  3-in-1 unit: soap, water, paper towel dispenser
 - Adjustable hinges.
 side-by-side to create a mirror wall.    510207I  2-in-1 unit: soap, hand dryer
 Models with air pulse hand dryer:
 Linking screws are provided.  510203SD  Soap dispenser
 Glass mirror and black glass strip    -  High speed: dries in 10 - 12 seconds.
 with illuminated pictograms.  - Pulsed air at 360km/h. Airflow: 36 l/second.  30-year warranty *    Thermostatic mixing valve for models with tap
 - Low energy consumption: 704W.  (3-year warranty for the hand dryer).
 - Noise level: 74 dBA.  50 years repairability  732012  PREMIX NANO thermostatic mixing valve FFM3/8"
 - Class I, IP23. CE marked.  * see General terms and conditions of sale  732115MEC  PREMIX NANO thermostatic mixing valve F1/2" ∅ 15mm
                      + 808012 for compression fittings + connector
 - 3-year warranty.
