TEMPOSTOP time flow urinal valve

Ref. 778000
Time flow 3 seconds
See variants See variants
TEMPOSTOP time flow urinal valve

Presentation

DESCRIPTION

TEMPOSTOP time flow urinal valve

Ref. 778000
Exposed time flow urinal valve:
For standard, siphon action, or stall urinals.
For wall-mounted installation.
Time flow ~3 seconds.
Flow rate pre-set at 0.15 l/sec. at 3 bar, can be adjusted.
Compatible with rain water.
Chrome-plated brass body M½".
Wall plate.
Angled for recessed inlet.
30-year warranty.

ADVANTAGES

Economie d'eau

Eco time flow 3 seconds

Anti-vandalisme

Chrome-plated solid brass

Endurance - Fiabilité

Withstands over 500 000 operations

Characteristics

TECHNICAL CHARACTERISTICS

TEMPOSTOP time flow urinal valve

Ref. 778000
Connector 1/2"
Technology Time flow
Flow rate 0.15 l/sec.
Certificates Logo VA Logo DoP
Warranty 30-Year
Repairability
TEMPOSTOP time flow urinal valve
Ref. 778000

Downloads

DOWNLOADS

TEMPOSTOP time flow urinal valve

Ref. 778000

To download one or several documents linked to this product, please select the type of file you require :

Spare parts

SPARE PARTS

TEMPOSTOP time flow urinal valve

Ref. 778000
1. 743003
Time flow cartridge

VARIANTS

777000 Straight for in-line inlet, Time flow 3s, M½"
