Additional fittings /

Floor trap 150 150mm Floor trap 100 100mm Floor trap Ø 114mm
For tiled or concrete floors For tiled or concrete floors For soft or vinyl floors

• Flow rate 36 lpm (meets standards). • Flow rate 36 lpm (meets standards). • Flow rate 36 lpm (meets standards).
• Water level 50mm. • Water level 50mm. • Water level 50mm.
• Bright polished stainless steel plate • Bright polished stainless steel grid • Bright polished stainless steel grid Ø 114mm.
and grid 150 150mm. 100 100mm. • Vertical or horizontal outlet integrated into
• Vertical or horizontal outlet integrated into • Vertical or horizontal outlet integrated into the height of the floor trap (saves height and
the height of the floor trap (saves height and the height of the floor trap (saves height and space in all dimensions). SHOWERS
space in all dimensions). space in all dimensions). • Height adjusts up to 85mm with extension.
• Height adjusts up to 70mm with extension. • Height adjusts up to 80mm with extension. • 30-year warranty.
• 30-year warranty. • 30-year warranty.
Ø 114
150x150 100x100
10-85
5-70 15-80 Ø 165
Ø 165
Ø 165
110 Ø 40
110 Ø 40 110 Ø 40
Ø 94
Ø 94 Ø 94
683001 682001 683002
Floor trap Floor trap Floor trap
Outlet Ø 40mm 683001 Outlet Ø 40mm 682001 Outlet Ø 40mm 683002
Outlet Ø 43mm 683001UK Outlet Ø 43mm 682001UK Outlet Ø 43mm 683002UK

Floor trap 140 140mm PREMIX NANO PREMIX COMPACT
For tiled or concrete floors Thermostatic mixing valve Thermostatic mixing valve
NEW

• Flow rate 18 lpm. • Thermostatic mixing valve for MW distribution. • Thermostatic mixing valve for MW distribution.
• Water level 18mm. • Temperature can be adjusted from 34 - 60°C. • Temperature can be adjusted from 30 - 60°C.
• Stainless steel body 140 140mm. • To be placed upstream of the shower. • To be placed upstream of the shower.
• Bright polished stainless steel grid fixed • Anti-scalding failsafe. • Anti-scalding safety.
by a stainless steel screw. • Filters and non-return valves. • Filters and non-return valves.
• PVC bell. • Thermal shocks are possible. 75 • Thermal shocks are possible.
• Vertical outlet Ø 40mm (provide elbow • Supplies one shower. Ø15 • For 1 to 3 showers.
for horizontal outlets). • 30-year warranty. • 30-year warranty.
• 30-year warranty. 75
120
3/8" 1/2"
68
70
140x140
1/2" 1/2"
Ø 110 3/8" 34 3/8" 40
52 Ø 15 34 Ø15
23 Ø 40 732012 732115
PREMIX NANO 733015
684000
Nickel, FFM⅜" 732012 PREMIX COMPACT
Polished, FFM⅜" 732016 M½" 733015
Nickel, M½" Ø 15mm 732115 M¾" 733020
Nickel, F½" Ø 15mm 732115MEC M½" Ø 15mm 733115
Floor trap 140 140mm 684000 Polished, M½" Ø 15mm 732116 M¾" Ø 15mm 733116

Showers 107
