/ Straight or angled shower curtain rail assembly kit

Fixing
Fixing plate
plate
2392
Tube
Tube
2396
2397
2398
2399
2400
Elbow
2393

Fixing plate Sleeve connector

• For Ø 20mm tubes. • To connect 2 straight tubes.
• Concealed fixings via 304 stainless steel plate. • Connects 2 Ø 20mm tubes.
• With push-fit connectors for mounting. • Dimensions: Ø 18 60mm.
• Supplied with 4 screws 4 30mm and 4 rawl plugs. • 30-year warranty.
• 30-year warranty.
49
Ø 18
Ø 62
60
2392 2390

Pack of 2 fixing plates 2392 Sleeve connector 2390

Elbow connector Connecting tubes

• To connect 2 Ø 20mm tubes. • Cut-to-size.
• 304 stainless steel. • Bright polished 304 stainless steel, Ø 20
• With push-fit connectors for mounting. 1mm thick.
• Dimensions: 150 150mm. • Tube Ø 20mm. 600-1000
• 30-year warranty. • Longer tubes available on request.
150
• 30-year warranty. 2396/2397/2398/2399/2400

150 Connecting tubes
600mm 2396
700mm 2397
2393 800mm 2398
900mm 2399
Elbow connector 2393 1,000mm 2400

52 Hygienic accessories
