BINOPTIC MIX 2 electronic basin mixer

Ref. 484000
Mains, recessed, stopcocks, L. 240mm
BINOPTIC MIX 2 electronic basin mixer

Presentation

DESCRIPTION

BINOPTIC MIX 2 electronic basin mixer

Ref. 484000
Provisional availability 2nd half
2026
.
Please contact the sales office to check availability.
Recessed satin electronic basin mixer:
230/6V mains supply.
Reduced-stagnation solenoid valve and electronic unit are integrated into the body of the mixer.
Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 - 6 lpm.
Scale-resistant aerator.
Adjustable duty flush (pre-set flush ~60 seconds every 24 hours after last use).
Wall-mounted stainless steel mixer.
Presence detection sensor at the end of the spout optimises detection.
Anti-blocking security.
Spout with smooth interior and low water volume (reduces bacterial development).
Side temperature control with adjustable maximum temperature limiter on mixers.
Set detection distance, duty flush and launch thermal shocks manually.
Suitable for people with reduced mobility.
30-year warranty.

ADVANTAGES

Economie d'eau

Exceptional water savings: 90%

Sans contact manuel

Hygiene: no manual contact

Rinçage périodique

Anti-bacterial proliferation duty flush

Maintenance aisée - Installation aisée

LED diagnostic aids

Characteristics

TECHNICAL CHARACTERISTICS

BINOPTIC MIX 2 electronic basin mixer

Ref. 484000
Supply 230/6V mains supply
Connector M½"
Technology Electronic
Spout length 240mm
Flow rate 3 lpm
Finish Satin
Certificates ACS
Warranty 30-Year

Downloads

DOWNLOADS

BINOPTIC MIX 2 electronic basin mixer

Ref. 484000

To download one or several documents linked to this product, please select the type of file you require :

VARIANTS

484010 Chrome-plated: L.240mm, recessed supply M1/2"
484010E Chrome-plated: L.240mm, recessed union M1/2", Bluetooth connectivity
482010 Chrome-plated: L.220mm, F3/8", stopcocks, for cross wall installation
48201015 Chrome-plated: L.220mm, Ø 15mm compression fittings, cross wall
482110 Chrome-plated: L.220mm, F3/8", for cross wall installation

VARIANTS

484010 Chrome-plated: L.240mm, recessed supply M1/2"
484010E Chrome-plated: L.240mm, recessed union M1/2", Bluetooth connectivity
482010 Chrome-plated: L.220mm, F3/8", stopcocks, for cross wall installation
48201015 Chrome-plated: L.220mm, Ø 15mm compression fittings, cross wall
482110 Chrome-plated: L.220mm, F3/8", for cross wall installation
