BINOPTIC MIX 2 electronic basin mixer

Ref. 474110E
Mains, deck-mounted, H. 170mm, Bluetooth®
BINOPTIC MIX 2 electronic basin mixer

Presentation

DESCRIPTION

BINOPTIC MIX 2 electronic basin mixer

Ref. 474110E
Provisional availability 2nd half
2025
.
Please contact the sales office to check availability.
Deck-mounted chrome-plated electronic basin mixer:
230/6V mains supply.
Reduced stagnation solenoid valve and electronic unit integrated into the body of the mixer.
Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 to 6 lpm.
Scale-resistant aerator.
Adjustable duty flush (~60 seconds every 24 hours after the last use).
Stainless steel mixer, 170mm high for semi-recessed basins.
Sensor at the end of the spout optimises detection.
PEX flexibles F3/8" with filters and non-return valves
Fixing reinforced by 2 stainless steel rods.
Anti-blocking security.
Smooth interior spout with low water volume (limits bacterial niches).
Side temperature control with adjustable maximum temperature limiter.
Set detection distance, duty flush and launch thermal shocks manually.
Bluetooth® version: advanced settings and operating data download via DELABIE Connect app.
Suitable for people with reduced mobility.
30-year warranty.

ADVANTAGES

Economie d'eau

90% water savings

Sans contact manuel

Hygiene: no manual contact

Rinçage périodique

Anti-bacterial proliferation duty flush

Bluetooth®

Easy to configure & monitor operation

Characteristics

TECHNICAL CHARACTERISTICS

BINOPTIC MIX 2 electronic basin mixer

Ref. 474110E
Supply 230/6V mains supply
Connector M3/8"
Technology Electronic
Drop height 170mm
Flow rate 3 lpm
Finish Chrome-plated
Certificates ACS
Warranty 30-Year

Downloads

DOWNLOADS

BINOPTIC MIX 2 electronic basin mixer

Ref. 474110E

To download one or several documents linked to this product, please select the type of file you require :

VARIANTS

474110 Chrome finish - mains supply 230/6V - F3/8"
47401015 Chrome finish - mains supply 230/6V - Ø 15mm compression fittings
474116 Chrome finish - 6V batteries - F3/8"
47400615 Brushed finish - 6V batteries - Ø 15mm compression fittings
47401615 Chrome finish - 6V batteries - Ø 15mm compression fittings
474100 Satin finish - mains supply 230/6V - F3/8"
47400015 Satin finish - mains supply 230/6V - Ø 15mm compression fittings
474106 Satin finish - 6V batteries - F3/8"
474130 Mains supply 230/6V - F3/8"
474136 Operated by 6V batteries - F3/8"

VARIANTS

474110 Chrome finish - mains supply 230/6V - F3/8"
47401015 Chrome finish - mains supply 230/6V - Ø 15mm compression fittings
474116 Chrome finish - 6V batteries - F3/8"
47400615 Brushed finish - 6V batteries - Ø 15mm compression fittings
47401615 Chrome finish - 6V batteries - Ø 15mm compression fittings
474100 Satin finish - mains supply 230/6V - F3/8"
47400015 Satin finish - mains supply 230/6V - Ø 15mm compression fittings
474106 Satin finish - 6V batteries - F3/8"
474130 Mains supply 230/6V - F3/8"
474136 Operated by 6V batteries - F3/8"
